HMC973ALP3ETR

Voltage Variable Attenuator 31dB Attenuation 5000MHz 16Pin LFCSP EP T/R

Product Details

The HMC973ALP3E is an absorptive Voltage Variable Attenuator VVA which operates from 0.5 to 5 GHz and is ideal in designs where an analog DC control signal must be used to control RF signal levels over a 26 dB amplitude range. It features a shunt-type attenuator controlled by an analog voltage, Vctrl. The HMC973ALP3E is an unidirectional device with optimum linearity performance achieved when the RF input signal is applied to the RFIN package lead. The HMC973ALP3E is housed in a RoHS compliant 3x3 mm QFN leadless package.

Applications

.

Point-to-point radio

.

Cellular/3G & WiMAX/4G infrastructure

.

Test instrumentation

.

Microwave sensors

.

Military, ECM & radar

### Features and Benefits

.

Wide attenuation range: 26 dB

.

Single positive voltage control: 0 to +5V

.

Absorptive topology

.

16 lead 3x3mm SMT package: 9 mm²
