MC912D60AMFUE8
MCU 16Bit HC12 HC12 CISC 60KB Flash 5V 80Pin PQFP Tray
Overview
The 68HC912D60A microcontroller unit MCU is a 16-bit device available in two package options, 80-pin QFP and 112-pin TQFP. On-chip peripherals include a 16-bit central processing unit CPU12, 60K bytes of flash EEPROM, 2K bytes of RAM, 1K bytes of EEPROM, two asynchronous serial communication interfaces SCI, a serial peripheral interface SPI, an enhanced capture timer ECT, two one on 80QFP 8-channel, 10-bit analog-to-digital converters ATD, a four-channel pulse-width modulator PWM, and a CAN 2.0 A, B software compatible module MSCAN12. System resource mapping, clock generation, interrupt control and bus interfacing are managed by the lite integration module LIM. The 68HC912D60A has full 16-bit data paths throughout, however, the external bus can operate in an 8-bit narrow mode so single 8-bit wide memory can be interfaced for lower cost systems. The inclusion of a PLL circuit allows power consumption and performance to be adjusted to suit operational requirements. In addition to the I/O ports available in each module, 16 2 on 80QFP I/O port pins are available with Key-Wake-Up capability from STOP or WAIT mode.
MoreLess
## Features
* 16-bit CPU12
* Multiplexed bus
* Two 8-bit ports with key wake-up interrupt 2 pins only are available on 80QFP and one I 2 C start bit detector 112TQFP only
* 60K byte flash EEPROM, made of a 28K module and a 32K module with 8K bytes protected BOOT section in each module 68HC912D60
* 60K byte ROM 68HC12D60
* 1K byte EEPROM
* 2K byte RAM
* 1M bit per second, CAN 2.0 A, B software compatible module
* Enhanced capture timer ECT
* 4 PWM channels with programmable period and duty cycle
