ST92T163R4T1L

8月16日- BIT全速USB MCU进行复合设备有16个端点， 20K ROM ， 2K RAM ， I2C ， SCI ，与MFT 8/16-BIT FULL SPEED USB MCU FOR COMPOSITE DEVICES WITH 16 ENDPOINTS, 20K ROM, 2K RAM, I2C, SCI, & MFT

GENERAL DESCRIPTION

INTRODUCTION

The ST9216x family brings the enhanced ST9 register-based architecture to a new range of high performance microcontrollers specifically designed for USB Universal Serial Bus applications. Their performance derives from the use of a

flexible 256-register programming model for ultrafast context switching and real-time event response. The intelligent on-chip peripherals offload the ST9 core from I/O and data management processing tasks allowing critical application tasks to get the maximum use of core resources.

■ Internal Memories: 20 Kbytes ROM/EPROM/OTP, 2 Kbytes RAM

■ Register oriented 8/16 bit core

■ 224 general purpose registers available as RAM, accumulators or index pointers

■ Minimum instruction cycle time: 167 ns @24 MHz CPU frequency

■ Low power modes: WFI, SLOW, HALT and STOP

■ DMA controller for reduced processor overhead

■ Full speed USB interface with DMA, compliant with USB specifications version 1.1 in normal voltage mode

■ USB Embedded Functions with 16 fully configurable endpoints buffer size programmable, supporting all USB data transfer types Isochronous included

■ On-chip USB transceiver and 3.3 voltage regulator

■ Multimaster I2C-bus serial interface up to 400KHz. with DMA capability

■ Serial Communications Interface SCI with DMA capability:

    – Asynchronous mode up to 315 Kb/s

    – Synchronous mode up to 3 MHz

■ External memory interface 8-bit data/16-bit address with DMA capability from the USB

■ 16-bit Multi-Function Timer 12 operating modes with DMA capability

■ 16-bit Timer with 8-bit prescaler and Watchdog

■ 6-channel, 8-bit A/D Converter ADC

■ 15 interrupt pins on 8 interrupt channels

■ 14 pins programmable as wake-up or additional external interrupts

■ 42 DIP56 or 44 QFP64 fully programmable I/Os with 6 or 8 high sink pads 10 mA @ 1 V

■ Programmable PLL clock generator RCCU using a low frequency external quartz 8 MHz

■ On-chip RC oscillator for low power operation

■ Low Voltage Detector Reset on some devices1

■ Rich instruction set with 14 addressing modes

■ Several operating voltage modes available on some devices1 :

    – Normal Voltage Mode

    – 8-MHz Low Voltage Mode

    – 16-MHz Low Voltage Mode

■ 0 - 24 MHz CPU clock operation @ 4.0-5.5 V all devices

■ 0 - 8 MHz CPU clock operation @ 3.0-4.0 V 8-MHz and 16-MHz Low Voltage devices

■ 0 - 16 MHz CPU clock operation @ 3.0-4.0 V 16-MHz Low Voltage devices only

■ Division-by-zero trap generation

■ 0oC to 70oC temperature range

■ Low EMI design supporting single sided PCB

■ Complete development tools, including assembler, linker, C-compiler, archiver, source level debugger and hardware emulators, and Real Time Operating System
