MPX2050DP

115 kPa，Freescale高量程压力差分/量规传感器在压力施加到传感器侧（差分）和大气压力侧（校准的）时，测量来源之间的压力差异。### 压力传感器，Freescale

0 to 50 kPa 0 to 7.25 psi 40 mV FULL SCALE SPAN TYPICAL

The MPX2050 series device is a silicon piezoresistive pressure sensors providing a highly accurate and linear voltage output — directly proportional to the applied pressure. The sensor is a single, monolithic silicon diaphragm with the strain gauge and a thin–film resistor network integrated on–chip. The chip is laser trimmed for precise span and offset calibration and temperature compensation.

Features

• Temperature Compensated Over 0°C to +85°C

• Unique Silicon Shear Stress Strain Gauge

• Easy to Use Chip Carrier Package Options

• Ratiometric to Supply Voltage

• Differential and Gauge Options

• ±0.25% Linearity MPX2050

Application Examples

• Pump/Motor Controllers

• Robotics

• Level Indicators

• Medical Diagnostics

• Pressure Switching

• Non–Invasive Blood Pressure Measurement
