0022288121

2.54毫米（ .100“ ）间距KK®头，分离式，直角表面贴装2.54毫米（ .100” ）间距KK®头，分离式，直角表面贴装 2.54mm .100" Pitch KK® Header, Breakaway, Right Angle Surface Mount 2.54mm .100" Pitch KK® Header, Breakaway, Right Angle Surface Mount

Connector Header Through Hole, Right Angle 12 position 0.100" 2.54mm

得捷:
CONN HEADER R/A 12POS 2.54MM

立创商城:
2.54mm 方针

贸泽:
Headers & Wire Housings HDR RA 1X12P .1" 324/120 SN

艾睿:
Use this unshrouded 0022288121 connector from Molex when board-to-board interconnects is required. This HDR connector&s;s 12 contacts that are made out of brass and plated with tin over nickel. It has a right angle body orientation. It has a maximum voltage rating of 250 V. Its pitch is 2.54 mm. This is a 1-row connector. It has a header type gender. This device has a maximum current rating of 4 A/contact. This product is 30.48 mm long, 2.49 mm tall and 12.3 mm deep. It uses the solder termination method. This connector has an operating temperature of -40 to 80 °C. 0022288121 is housed in black nylon.

Verical:
Conn Unshrouded Header HDR 12 POS 2.54mm Solder RA Thru-Hole KK® Bag
