RJF 71B

AMPHENOL SOCAPEX  RJF 71B  插座, RJ45 密封 防松螺母

The RJ Field series Ethernet Connection System for use with harsh environment. The RJField allows to use an Ethernet class D/Cat.5e connection for 10 BaseT, 100 BaseTX or 1000 BaseT networks in harsh environment. With the patented RJStop® system you can use a standard RJ45 cordset in a metallic plug which will protect it from shocks, dust and fluids. No hazardous in-field cabling and grounding. This metallic plug is connected into a receptacle, using a fast 1/4 turn bayonet coupling mechanism providing both audible and visual coupling. On the receptacle, one female RJ45 is soldered onto a PCB allowing for the back terminations of another female RJ45, a RJ45 cordset and solder termination. The RJ45 cordset shielding is transmitted to the RJ45 receptacle through lateral grounding fingers. For an outstanding EMI protection, the conductive plating versions Ni/Cd with metalized receptacle inserts, transmit the shielding to the connector shells and finally to the panel.

.

Bayonet coupling audible and visual coupling signal

.

4 Mechanical coding/polarization possibilities by the user insert rotation

.

RJ45 cordset retention in the plug - 100N in the axis

.

500 Minimum mating cycles

.

IP67 Sealing
