68021-160HLF

Mount this unshrouded 68021-160HLF header connector from FCI on a jumper post on your PCB to support physical configuration options. This HDR connector&s;s 60 contacts that are made out of phosphor bronze and plated with gold over nickel|gxt over nickel. It has a maximum voltage rating of 1500 VAC. This is a 2-row connector. It has a header type gender. Its pitch is 2.54 mm. It has a right angle body orientation. This device has a maximum current rating of 3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. It uses the solder termination method. 68021-160HLF is housed in black nylon|polychlorinated terphenyl|liquid crystal polymer. This product is 76.2 mm long, 4.83 mm tall and 12.44 mm deep. This connector has an operating temperature of -65 to 125 °C.

Connector Header Through Hole, Right Angle 60 position 0.100" 2.54mm

得捷:
CONN HEADER R/A 60POS 2.54MM

艾睿:
Mount this unshrouded 68021-160HLF header connector from FCI on a jumper post on your PCB to support physical configuration options. This HDR connector&s;s 60 contacts that are made out of phosphor bronze and plated with gold over nickel|gxt over nickel. It has a maximum voltage rating of 1500 VAC. This is a 2-row connector. It has a header type gender. Its pitch is 2.54 mm. It has a right angle body orientation. This device has a maximum current rating of 3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. It uses the solder termination method. 68021-160HLF is housed in black nylon|polychlorinated terphenyl|liquid crystal polymer. This product is 76.2 mm long, 4.83 mm tall and 12.44 mm deep. This connector has an operating temperature of -65 to 125 °C.
