TSW-107-14-S-S

Conn Unshrouded Header HDR 7POS 2.54mm Solder ST Thru-Hole

Connector Header Through Hole 7 position 0.100" 2.54mm

欧时:
Classic PCB HDR Strips 0.100"

得捷:
CONN HEADER VERT 7POS 2.54MM

艾睿:
Thanks to Samtec&s;s unshrouded TSW-107-14-S-S header connector, you can reduce the possibility of accidentally shorting out any pins on your printed circuit. This HDR connector&s;s 7 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2.54 mm. It has a header type gender. It has a straight body orientation. This is a 1-row connector. It has a maximum voltage rating of 550 VAC. This device has a maximum current rating of 6.3 A/contact. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. This product is 17.78 mm long, 10.67 mm tall and 2.54 mm deep. TSW-107-14-S-S is housed in black polyester.

Newark:
# SAMTEC  TSW-107-14-S-S  .025 Sq. Terminal Strips
