SN6501-MULXFMR-EVM

TEXAS INSTRUMENTS  SN6501-MULXFMR-EVM  评估模块, SN6501, 高初级侧电流驱动, 低纹波的整流输出

The is an Evaluation Module for evaluate the operation and performance of SN6501, a transformer driver for isolated power supplies. The board configured with five independent circuits providing options to operate using either a 3.3 or 5VDC input and provides one of five isolated 3.3VDC +5VDC outputs. Two of the circuits include LDO"s to regulate the output. The five configurations include 3VDC-to-3VDC with no LDO, 5VDC-to-5VDC with no LDO, 3VDC-to-5VDC with no LDO, 3VDC-to-5VDC with and LDO and a 3VDC/5VDC-to-3VDC/5VDC with a selectable LDO output.

.

Push-pull driver for small transformers

.

Single 3.3 or 5V supply

.

High primary-side current drive

.

Low ripple on rectified output
