S6AL

NKK SWITCHES  S6AL  拨动开关, DPDT, 20A, 125VAC

Standard size toggles with zinc plated steel covers and locking toggles are sturdily built. The 12mm bushing, with included mounting hardware, fits most panel mount applications. Up to 4 poles with 6 circuits are available. Heat tolerant resin case provides high arc resistance. Long life contact mechanisms in these models assures long life. Solder lug, screw lug, and quick connect terminals are available.

欧时:
Toggles,DPDT,20A 125Vac

贸泽:
拨动开关 DPDT ON-ON MED CAP SOLDER LUG

e络盟:
开关, 拨动, DPDT, 20A, 125VAC

艾睿:
This medium capacity S6AL toggle switch from NKK Switches acts like a light switch to turn on or off any part of your circuit. This device has a maximum current rating of 20 A @ 125VAC 30VDC. It has a DPDT configuration. This toggle switch has a minimum operating temperature of -10 °C and a maximum of 70 °C. The S6AL toggle switch has a solder lug termination style. This product is 31.2 mm long, 69.1 mm tall and 18.6 mm deep. The maximum AC voltage rating is 250 VAC and the maximum DC voltage rating is 30 VDC.

Allied Electronics:
SWITCH, TOGGLE, LOCKING LEVER, DPDT, SOLDER TERMINALS, ON-NONE-ON, 20A, 125 VAC

Chip1Stop:
Switch Toggle ON None ON DPDT Locking Lever Solder Lug 20A 250VAC 30VDC Panel Mount with Threads

Verical:
Switch Toggle ON None ON DPDT Locking Lever Solder Lug 20A 250VAC 30VDC Panel Mount with Threads

Newark:
Toggle Switch, DPDT, Non Illuminated, On-None-On, Panel, 20 A

Powell:
STD SIZE TOGGLE/LOW TO HIGH CAPACITY
