EAC2420SP

EATON CUTLER HAMMER EAC2420SP Current Sensor, CurrentWatch™ EAC Series , Split Core, 100A to 200A, 4 to 20mA Output, 24VDC

Solid-core housing models are ideal for new equipment installations where the conductor wire is ran through the fixed aperture. Split-core models are perfect for retrofit applications because the housing can be opened to fit around an existing conductor. As such, split-core current sensors are easy to install, without re-wiring and shutting down a process for long periods of time. The simplicity of installing split-core models reduces overall installation costs.

**Sensors**

Current sensors operate by monitoring current flow in equipment. The current magnitude is converted into a linear and proportional analog signal 4-20 mA, 0-5 V or 0-10 V. Small changes in current can be detected, avoiding costly repairs and mechanical problems before they occur. These sensors are magnetically isolated, contain internal signal conditioning, are safer to use than current transformers, do not require additional circuitry, and are completely self-contained in one compact package.

**Features: **

* Complete Family of AC and DC Current Sensors

* Handy Features Such as Split-Core Housings That Wrap Around Existing Wires, and Completely Self-Powered Models

* Field Adjustable Current Settings and a Variety of Output Types Analog and Discrete

* Perfect for Providing Predictive Diagnostics on Machine Equipment, Monitoring and Feedback, Over Current Detection, and Energy Reduction

* 5-Year Warranty

* UL and CE Approvals

* Accurate Current Sensing for Proportional 4-20 mA Output for All Types of Applications

* Outputs Are Magnetically Isolated from the Input for Safety and Voltage Drops

* Current Ranges Upto 200 A with Jumper Position, Solid Core and Split Core Modules for New and Existing Applications Requiring Reliable Feedback on Electrified Equipment

* 4-20 mA Output

* Solid Core and Split Core Housings

* LED Visual Indication
