1013730000

WEIDMULLER  1013730000  插拔式接线端子, 6 路, 300 V, 10 A, 5.08 mm, 26 AWG, 12 AWG

The is a 6-pole orange female PCB Plug-in Connector with push-in wire connection. The BLF 5.08HC/06/180 SN OR BX connector has tinned CuSn contact with 4 to 8µm Sn hot-dip tinned layer structure of plug contact and a PBT insulator. The BLF 5.08HC PUSH IN version of the BLZP 5.08HC female connector is not only different in terms of connection system and it also has a more compact design. Weidmüllers innovative PUSH IN spring connection system stands for the future of easy and tool-free wire connection. In terms of versatility, the BLF 5.08HC offers just as much as the version which served as a model. The 3 tested-and-proven wire outlet directions provide the usual flexibility for application-specific design, 4 flange variations and the patented release latch allow the locking concept to be based on the requirements of the user.

.

Safe from finger touch

.

>=10⁸R Insulation resistance

.

4.5mR Volume resistance

.

IP20 Protection

.

UL94V-0 Flammability

.

-50 to 100°C Operating temperature range
