DM990013-BNDL
开发套件, CEC1702物联网套件, Microsoft Azure认证, DICE支持
CEC1702 IoT development kit which easily incorporate security into designs. A Microsoft certified Azure IoT Starter Kit with DICE support for fast development. The kit contains the CEC1x02 development board including the CEC1702PIM part # DM990013. The CEC1x02 development board is a new Evaluation-board that can be used for development, customer evaluation and demos. This smart connected solution is comprised of an MCU with crypto accelerators with Wi-Fi communication providing the base-level building blocks for your IoT node. The kit allows users to easily add additional functionality, such as temperature sensing to their designs.
- .
- Secure boot for establishing a chain of trust
- .
- Device Identifier Composition Engine DICE capable for protection of nodes
- .
- MS Azure Certified Kit for fast development with minimal risk
- .
- Connector for Plug in Module PIM for the CEC1702
- .
- Compact, high contrast, serial graphic LCD display module with backlight
- .
- Serial Quad I/O SQI flash
- .
- OTP programmability in CEC1702
- .
- Two expansion headers compatible with MikroElektronika mikroBUS™ expansion interface
- .
- Wi-Fi 7 click board for cloud connectivity connected to mikroBUS slot 1 on the board
- .
- THERMO 5 click board from MikroElektronika connected to mikroBUS slot 2
