MKDSN2,5/4-5.08
PHOENIX CONTACT MKDSN2,5/4-5.08 线至板接线端子, 4 路, 400 V, 16 A, 24 AWG, 14 AWG, 2.5 mm²
The is a 4-position 5.08mm PCB Terminal Block with screw connection for wave soldering processes, currents up to 24A. PA polyamide insulator, Sn solder pin surface. Low-profile design, with housing overlapping, screw connection mounting, soldering method, A3 cylindrical cage and M3 connection thread.
- .
- UL94V-0 Flammability rating
- .
- 0° Conductor/PCB connection direction
- .
- Cross section of up to 2.5mm²
