DG612DJ

高速，低毛刺D / CMOS模拟开关 High-Speed, Low-Glitch D/CMOS Analog Switches

DESCRIPTION

The DG611/612/613 feature high-speed low-capacitance lateral DMOS switches. Charge injection has been minimized to optimize performance in fast sample-and-hold applications.

FEATURES

• Fast Switching - tON: 12 ns

• Low Charge Injection: ± 2 pC

• Wide Bandwidth: 500 MHz

• 5 V CMOS Logic Compatible

• Low rDSon: 18 Ω

• Low Quiescent Power : 1.2 nW

• Single Supply Operation

BENEFITS

• Improved Data Throughput

• Minimal Switching Transients

• Improved System Performance

• Easily Interfaced

• Low Insertion Loss

• Minimal Power Consumption

APPLICATIONS

• Fast Sample-and-Holds

• Synchronous Demodulators

• Pixel-Rate Video Switching

• Disk/Tape Drives

• DAC Deglitching

• Switched Capacitor Filters

• GaAs FET Drivers

• Satellite Receivers
