MTU1D0505MC

MURATA POWER SOLUTIONS  MTU1D0505MC  直流/直流转换器, 隔离电路板安装, SMD, 1W, 5V, 100mA, -5V, 100mA

The is a 2-output 1W board-mount isolated high performance DC/DC Converter with a footprint reduction of over 50% from the previous generation of SMD DC/DC, the device offers 1W of available output power over the full industrial temperature range of -40 to 85°C. The device is more efficient and offers improved regulation performance for applications where a wide output voltage variation cannot be tolerated. The device is suitable for all applications where high volume production is envisaged.

.

Patent protected

.

Toroidal magnetics

.

Multi-layer ceramic capacitors

.

1kVDC Isolation hi pot test

.

Footprint over pins 0.69cm²

.

Power density 1.71W/cm³

.

8% Maximum load regulation

.

30mVp-p Maximum ripple and noise

.

84% Typical efficiency

.

18pF Isolation capacitance

.

1.8ms Start-up time
