09-0130-70-12

Cable SocketsFrom Binder, this Series 723 miniature cable mount socket is screw-locking for secure and reliable mating attenuation. Easy to assemble and featuring internal strain relief, this connector has a robust metal construction. When mated, Series 723 connections are sealed to IP67 which means complete protection from contact dust and excellent protection against water. ### Binder 723 系列Binder 723 系列插头和插座具有黄铜螺母螺钉耦合机制特性且塑料插片带焊接端子。 螺钉耦合机制带有衬垫，密封电缆安装连接器，以直插入匹配或锁定时符合 IP67 等级，或带有相关机架安装连接器。数目 | 2 | 3 | 4 | 6 | 7 | 8 | 12 | 24 ---|---|---|---|---|---|---|---|--- 电流额定值 A | 7 | 7 | 6 | 5 | 5 | 5 | 3 | 1 电压额定值 Vac | 250 | 250 | 250 | 250 | 250 | 60 | 60 | 60 最大线规 mm² | 0.75 |   |   |   |   |   | 0.25 | 0.14 电缆出口尺寸 | 4 - 6mm |   |   |   |   |   | 6 - 8mm |   触点材料，引脚 | 黄铜 |   |   |   |   |   |   |   触点材料，插座 | 青铜 |   |   |   |   |   |   |   触点镀层 | 银 |   |   |   |   |   | 金 |   触点电阻 | ≥5mΩ |   |   |   |   |   | ≤3mΩ |   绝缘电阻 | ≥1010Ω |   |   |   |   |   |   |   接合次数 | >500 |   |   |   |   |   |   |   工作温度 | -40°C 至 +85°C |   |   |   |   |   |   |   电缆连接器材料 | PA66 |   |   |   |   |   |   |   面板连接器材料 | 镀镍压铸锌 |   |   |   |   |   |   |   易燃性等级 | UL94-0（插件），UL94 HB（电缆连接器外壳） |   |   |   |   |   |   |

Cable Sockets

From , this Series 723 miniature cable mount socket is screw-locking for secure and reliable mating attenuation. Easy to assemble and featuring internal strain relief, this connector has a robust metal construction. When mated, Series 723 connections are sealed to IP67 which means complete protection from contact dust and excellent protection against water.

欧时:
12路 电缆安装 直向 圆形连接器 插头, 插座触点

e络盟:
圆形连接器, 723 Series, 电缆安装插座, 12 触点, 焊接插座, 螺纹, 尼龙聚酰胺主体
