POE13P-12LD

COILCRAFT  POE13P-12LD  脉冲变压器, 1:0.5, 127 µH, 0.199 ohm, 1.5 kV

The is a Flyback Transformer with ferrite core and tin-silver-copper over tin over nickel over phosphor bronze terminations. This transformer is developed for Powered Devices PD in IEEE 802.3af compliant PoE 3, 7 and 13W applications.

.

Designed to operate in continuous mode at 250kHz with an input of 36 to 72VDC

.

1500Vrms 1 minute isolation from primary and bias to secondary

.

500Vrms 1 minute isolation between all other windings

.

250kHz Switching frequency

.

12V, 20mA Bias winding output
