AD526ADZ
PGA，Analog Devices### 可编程增益放大器 PGA可编程增益放大器是运算、仪表或差分放大器，其中增益可进行编程或选择，方法是使用串行通信链路通过硬件（集成电路引脚选择）或软件实现。
可编程增益放大器 PGA，Analog Devices
### 可编程增益放大器 PGA
可编程增益放大器是运算、仪表或差分放大器，其中增益可进行编程或选择，方法是使用串行通信链路通过硬件（集成电路引脚选择）或软件实现。
得捷:
IC OPAMP PGA 1 CIRCUIT 16CDIP
立创商城:
AD526ADZ
欧时:
可编程增益放大器 PGA，Analog Devices### 可编程增益放大器 PGA可编程增益放大器是运算、仪表或差分放大器，其中增益可进行编程或选择，方法是使用串行通信链路通过硬件（集成电路引脚选择）或软件实现。
艾睿:
SP Amp Variable Gain Amp Single ±16.5V 16-Pin SBCDIP Tube
安富利:
The AD526 is a single-ended, monolithic software programmable gain amplifier SPGA that provides gains of 1, 2, 4, 8 and 16. It is complete, including amplifier, resistor network and TTL-compatible latched inputs, and requires no external components.Low gain error and low nonlinearity make the AD526 ideal for precision instrumentation applications requiring programmable gain. The small signal bandwidth is 350 kHz at a gain of 16. In addition, the AD526 provides excellent dc precision. The FETinput stage results in a low bias current of 50 pA. A guaranteed maximum input offset voltage of 0.5 mV max C grade and low gain error 0.01%, G = 1, 2, 4, C grade are accomplished using Analog Devices’ laser trimming technology.To provide flexibility to the system designer, the AD526 can be operated in either latched or transparent mode. The force/sense configuration preserves accuracy when the output is connected to remote or low impedance loads.The AD526 is offered in one commercial 0°C to +70°C grade, J, and three industrial grades, A, B and C, which are specified from -40°C to +85°C. The S grade is specified from -55°C to +125°C. The military version is available processed to MILSTD 883B, Rev C. The J grade is supplied in a 16-lead plastic DIP, and the other grades are offered in a 16-lead hermetic side-brazed ceramic DIP.
Chip1Stop:
SP Amp Variable Gain Amp Single ±16.5V 16-Pin SBCDIP Tube
Verical:
SP Amp Variable Gain Amp Single ±16.5V 16-Pin SBCDIP Tube
Newark:
# ANALOG DEVICES AD526ADZ Programmable/Variable Amplifier, 1 Channels, 1 Amplifier, 350 kHz, -55 °C, 125 °C, ± 4.5V to ± 16V
罗切斯特:
AD526 - Software Programmable Gain Amplifier
DeviceMart:
IC AMP PGA 10MA 16CDIP
Win Source:
IC OPAMP PGA 4MHZ 16CDIP
