1836299

Phoenix Contact PCB 接线端子块 COMBICON MCV 系列 2路 5.08mm节距 1836299, 焊接端接, 8A

2 针位端子块 接头，公引脚，带罩（4 面） 0.200"（5.08mm） 垂直 - 通孔

得捷:
TERM BLOCK HDR 2POS VERT 5.08MM

贸泽:
可插拔接线端子 2 Pos 5.08mm pitch Through Hole Header

艾睿:
As an added safety precaution, the shrouded 1836299 header connector from Phoenix Contact will prevent and protect components on your circuit board from accidentally touching each other. This HDR connector has 2 contacts that are plated with tin. It has a straight body orientation. Its pitch is 5.08 mm. It has a header type gender. It has a maximum voltage rating of 320 V. This is a 1-row connector. This device has a maximum current rating of 8 A. It uses the solder termination method. 1836299 is housed in green polybutylene terephthalate. This product is 10.16 mm long, 9.2 mm tall and 7.25 mm deep.

Verical:
Conn Shrouded Header 4 Sides HDR 2 POS 5.08mm Solder ST Thru-Hole

MASTER:
PCB headers - nominal current: 8 A - rated voltage III/2: 320 V - nominal cross section: 1.5 mm² - number of positions: 2 - pitch: 5.08 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.

Online Components:
Conn Shrouded Header HDR 2 POS 5.08mm Solder ST Thru-Hole

Electro Sonic:
PCB headers - nominal current: 8 A - rated voltage III/2: 320 V - nominal cross section: 1.5 mm² - ...
