TSW-126-06-T-S

SAMTEC TSW-126-06-T-S Board-To-Board Connector, 2.54mm, 26Contacts, Header, TSW Series, Through Hole, 1Rows

针座通孔 26 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 26POS 2.54MM

艾睿:
Make strong and binding connections on your circuit boards by adopting this unshrouded TSW-126-06-T-S connector from Samtec. This HDR connector&s;s 26 contacts that are made out of phosphor bronze and plated with tin over nickel. It has a header type gender. Its pitch is 2.54 mm. This is a 1-row connector. It has a straight body orientation. It has a maximum voltage rating of 550 VAC. This device has a maximum current rating of 6.3 A/contact. This connector has an operating temperature of -55 to 105 °C. TSW-126-06-T-S is housed in black polyester. It uses the solder termination method. This product is 66.04 mm long, 5.21 mm tall and 2.54 mm deep.

Newark:
# SAMTEC TSW-126-06-T-S Board-To-Board Connector, 2.54 mm, 26 Contacts, Header, TSW Series, Through Hole, 1 Rows

TSW-126-06-T-S详细参数

TSW-126-06-T-S PDF数据文档
