SRP1245A-3R3M

BOURNS  SRP1245A-3R3M  表面贴装功率电感器, AEC-Q200 SRP1245A系列, 3.3 µH, ± 20%, 屏蔽, 9200 µohm, 15 A

SRP1245A 系列磁性屏蔽式功率器

Bourns SRP 系列高电流电感器具有羰基粉芯且符合 AEC-Q200。

**特点和优势：**

SRP1245A 系列电感器具有屏蔽结构

羰基粉芯

高饱和电流

电感范围 0.33 μH 至 18 μH

符合 AEC-Q200

符合 RoHS 标准且无卤

应用包括汽车系统（驾驶员辅助、信息、娱乐和照明）、

直流-直流转换器和电源

得捷:
FIXED IND 3.3UH 15A 9.2 MOHM SMD

立创商城:
3.3uH ±20% 15A 6.8mΩ

欧时:
Bourns SRP1245A 系列 屏蔽 羰基粉芯材 3.3 μH 绕线贴片电感器 SRP1245A-3R3M, ±20%容差, 15A Idc

e络盟:
功率电感SMD, 3.3 µH, 15 A, 屏蔽, 32 A, SRP1245A 系列, 13.5mm x 12.5mm x 4.8mm

艾睿:
This power SRP1245A-3R3M surface mount inductor from Bourns is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has an operating temperature range of -40 °C to 150 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This device utilizes wirewound technology. It has an inductance of 3.3u H. This product is 14 mm long, 5 mm tall and 12.8 mm deep. It has a tolerance of 20%. This SMD inductor has a maximum DC current of 15 A with a maximum resistance of 9.2m Ohm. Its test frequency is 100K Hz, while its minimum self-resonant frequency is 22MTyp Hz.

Allied Electronics:
Inductor; Shielded Power; AEC-Q200; 3.3uH 20% SMT 1245

安富利:
Ind Power Shielded 3.3uH 20% 100KHz Carbonyl Powder 15A T/R

Chip1Stop:
Inductor Power Shielded Wirewound 3.3uH 20% 100KHz 20Q-Factor Carbonyl Powder 15A 9.2mOhm DCR Automotive T/R

Verical:
Inductor Power Shielded Wirewound 3.3uH 20% 100KHz 20Q-Factor Carbonyl Powder 15A 0.0092Ohm DCR Automotive T/R

Newark:
# BOURNS  SRP1245A-3R3M  Surface Mount Power Inductor, AEC-Q200 SRP1245A Series, 3.3 H, 20%, Shielded, 9200 ohm, 15 A

Online Components:
Inductor Power Shielded Wirewound 3.3uH 20% 100KHz 20Q-Factor Carbonyl Powder 15A 9.2mOhm DCR Automotive T/R

Electro Sonic:
Inductor Power Shielded Wirewound 3.3uH 20% 100KHz 20Q-Factor Carbonyl Powder 15A 0.0092Ohm DCR Automotive T/R
