TSW-116-14-S-S

Conn Unshrouded Header HDR 16POS 2.54mm Solder ST Thru-Hole

Connector Header Through Hole 16 position 0.100" 2.54mm

得捷:
CONN HEADER VERT 16POS 2.54MM

艾睿:
Use this unshrouded TSW-116-14-S-S header connector from Samtec where IDC ribbon cables are used. This HDR connector&s;s 16 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2.54 mm. It has a maximum voltage rating of 550 VAC. It has a header type gender. It has a straight body orientation. This is a 1-row connector. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This product is 40.64 mm long, 10.67 mm tall and 2.54 mm deep. TSW-116-14-S-S is housed in black polyester. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method.
