TSW-111-05-G-D

SAMTEC TSW-111-05-G-D Board-To-Board Connector, 2.54mm, 22Contacts, Header, TSW Series, Through Hole, 2Rows

针座 通孔 22 位置 0.100"(2.54mm)


得捷:
CONN HEADER VERT 22POS 2.54MM


艾睿:
This unshrouded TSW-111-05-G-D header connector from Samtec reduces the possibility of accidentally shorting pins when a board is being used. This HDR connector&s;s 22 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 550 VAC. It has a straight body orientation. This is a 2-row connector. Its pitch is 2.54 mm. It has a header type gender. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This product is 27.94 mm long, 5.21 mm tall and 5.08 mm deep. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. TSW-111-05-G-D is housed in black polyester.


安富利:
Conn Unshrouded Header HDR 22 POS 2.54mm Solder ST Thru-Hole


Verical:
Conn Unshrouded Header HDR 22 POS 2.54mm Solder ST Top Entry Thru-Hole Bulk


Newark:
# SAMTEC  TSW-111-05-G-D  Board-To-Board Connector, 2.54 mm, 22 Contacts, Header, TSW Series, Through Hole, 2 Rows
