EB038

MATRIX  EB038  继电器板套件, E-BLOCKS

The quad relay board was designed to switch four relays on and off as a direct response to the low voltage input of an EB006 multiprogrammer board. This in turn allows the user to switch multiple devices ie, motors simultaneously. Quad relay board creates an interface between an upstream e-block and apparatus operating at a higher voltage. Each of the PCB mounted relays is rated at 12V/6A and contains a 400R coil.

.

Provides the capacity to operate two circuits at different voltage levels

.

Provides the ability to operate up to four devices ie, motors at varying speeds

.

Employs LEDs for instantaneous acknowledgment of relay setting

.

E-blocks compatible

The EB038 is powered from the 14V output on the EB006 multiprogrammer.
