68498-411HLF

As an added safety precaution, the unshrouded 68498-411HLF header connector from FCI will prevent and protect components on your circuit board from accidentally touching each other. This HDR connector&s;s 11 contacts that are made out of phosphor bronze and plated with tin over nickel. This is a 1-row connector. It has a right angle body orientation. Its pitch is 2.54 mm. It has a header type gender. It has a maximum voltage rating of 1500 VAC. This device has a maximum current rating of 3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -65 to 125 °C. It uses the solder termination method. This product is 27.94 mm long, 2.41 mm tall and 12.44 mm deep. 68498-411HLF is housed in black polychlorinated terphenyl|liquid crystal polymer.

针座连接器 通孔，直角 11 位置 0.100"（2.54mm）

得捷:
CONN HEADER R/A 11POS 2.54MM

艾睿:
BergStik®, Board to Board connector, Unshrouded Header, Through Hole, Single Row, 11 Positions, 2.54 mm Pitch, Right Angle, 5.84 mm 0.23 in. Mating, 5.59 mm 0.22 in. Tail
