RJD2A23D30E

RELAY SOLID STATE, DUAL SCR OUTPUT, 4-32VDC, 2X30A, 24-280VAC

Solid State Relays 2 Independently Switched Poles Integrated Heatsink, 2x45 A Current Rating

Solid state relays with heat sinks integrated directly onto the relay provide an excellent alternative to environmentally hazardous mercury relays. The IP20 touch-safe cover is easily removed to facilitate connection via ring terminals, and then the touch-safe cover can be quickly snapped back into place. Higher rated relays 75 and 90 A with integrated cooling fans are also available. Types ending with the "P" suffix feature an integrated fan and over-temperature protection. UL recognized, CSA certified and CE compliant.

* User Friendly — Just Snap onto DIN Rail

* Ideal Alternative to Mercury Relays

* One-, Two- or Three-Pole Switching

* Zero Switching for Resistive/Motor Loads

* Random Switching Available

* Built-In Snubber Network

* LED Indication

* AC and/or DC Control Voltage

* Up to 70 A Output Current

* Higher Rated Outputs Available Upon Request

* Up to 660 VAC Switching

* Up to 1200 Vp Non-Repetitive Voltage
