PM0603-47NJ-RC

PM0603系列 - 高Q片状电感器 PM0603 Series - High Q Chip Inductors

无屏蔽 绕线 器 280 毫欧 0603（1608 公制）

得捷:
FIXED IND 47NH 600MA 280MOHM SMD

立创商城:
47nH ±5% 600mA 280mΩ

艾睿:
This chip PM0603-47NJ-RC surface mount inductor from Bourns is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has an operating temperature range of -40 °C to 125 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. It has an inductance of 47n H. This product is 1.85 mm long, 1.2 mm tall and 1.25 mm deep. Its test frequency is 200M Hz, while its minimum self-resonant frequency is 2.1G Hz. It has a tolerance of 5%. This device utilizes wirewound technology. This SMD inductor has a maximum DC current of 600m A with a maximum resistance of 280m Ohm.

安富利:
Ind Chip Wirewound 47nH 5% 200MHz 35Q-Factor Alumina 600mA 0603 T/R

Verical:
Inductor Chip Wirewound 47nH 5% 200MHz 35Q-Factor Alumina 600mA 280mOhm DCR 0603 T/R

Newark:
# BOURNS JW MILLER  PM0603-47NJ-RC  Surface Mount High Frequency Inductor, PM0603 Series, 47 nH, 600 mA, 0603 [1608 Metric], Wirewound

MASTER:
Inductor RF Wirewound 0.047uH 5% 200MHz 35Q-Factor Alumina 0.6A 0.28Ohm DCR 0603 T/R

Electro Sonic:
Inductor RF Wirewound 0.047uH 5% 200MHz 35Q-Factor Alumina 0.6A 0.28Ohm DCR 0603 T/R
