FP20R06W1E3

EasyPIM模块海沟/ Fieldstopp IGBT3和发射极控制二极管3和NTC EasyPIM module with Trench/Fieldstopp IGBT3 and Emitter Controlled 3 diode and NTC

The is an EasyPIM™ 1B PIM IGBT Module with Trench/field-stop IGBT3, emitter controlled 3 diode and NTC. It is suitable for auxiliary inverters and air conditioning.

.

Low switching losses

.

VCEsat with positive temperature coefficient

.

Al2O₃ substrate with low thermal resistance

.

Compact design

.

Solder contact technology

.

Rugged mounting due to integrated mounting clamps

.

Compact module concept

.

Configuration flexibility
