TS339CDT

TS339 系列 SOP14 低电源电流 微功率 CMOS四通道电压比较器

The TS339 device is a micro-power, CMOS, quad voltage comparator with extremely low consumption of 9 μA typ./comparator 20 times less than the bipolar LM339. Similar performances are offered by the quad micro-power comparator TS3704 with a push-pull CMOS output. Thus response times remain similar to the LM339 device.

**Key Features**

.

Extremely low supply current: 9 μA typ./comparator

.

Wide single supply range 2.7 V to 16 V or dual supplies ±1.35 V to ±8 V

.

Extremely low input bias current: 1 pA typ.

.

Extremely low input offset current: 1 pA typ.

.

Input common-mode voltage range includes GND

.

High input impedance: 1012 Ω typ.

.

Fast response time: 1.5 μs typ. for 5 mV overdrive

.

Pin-to-pin and functionally compatible with bipolar LM339 device
