R1121N501B

R1121N501B LDO电压调整器/稳压电源IC 5V 170mV/0.17V SOT-153/SOT23-5 marking/标记 UO 短路保护 过热保护

电路数量Number of Regulators| 1 \---|--- 输入电压VINVoltage - Input| 9V 输出电压VOUTVoltage - Output| 5V 输出电流IoCurrent - Output| 100mA/0.1A 最大压降VDOVoltage - Dropout| 170mV/0.17V 带使能脚EN/CEON/OFF功能With Enable Pin| 无 No 最大耗散功率PdPower dissipation| 250mW/0.25W Description & Applications| LOW NOISE 150mA LDO REGULATOR ;•Ultra-Low Supply Current 35µA •Standby Mode 0.1µA • Low Dropout Voltage0.2V IOUT = 100mA • High Ripple Rejection 70db f = 1kHz • Low Temperature-Drift Coefficient of Output Voltage ±100ppm/°C •Excellent Line Regulation 0.05%/V •High Accuracy Output Voltage ±2.0% •Power source for cellular phones such as GSM, CDMA and various kind of PCSs. •Power source for domestic appliances such as cameras, VCRs and camcorders. •Power source for battery-powered equipmen 描述与应用| 低噪声150MA LDO稳压器;•超低电源电流35μA •待机模式0.1μA？ •低压降Voltage0.2V（IOUT=百毫安） •高纹波抑制70dB（F =1kHz时） •低温度漂移系数的输出电压温度系数±100ppm/°C •卓越的线路调整率0.05％/ V •高输出电压精度±2.0％？ •蜂窝电话如GSM，CDMA和各类的PCS的动力源。 •电源为国内家电，如照相机，录像机和摄像机。 •电源为电池供电设备。
