TSW-136-23-T-D

SAMTEC TSW-136-23-T-D Board-To-Board Connector, 2.54mm, 72Contacts, Header, TSW Series, Through Hole, 2Rows

针座 通孔 72 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 72POS 2.54MM

艾睿:
Make strong and binding connections on your circuit boards by adopting this unshrouded TSW-136-23-T-D connector from Samtec. This HDR connector&s;s 72 contacts that are made out of phosphor bronze and plated with tin over nickel. Its pitch is 2.54 mm. It has a header type gender. It has a maximum voltage rating of 550 VAC. It has a straight body orientation. This is a 2-row connector. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This product is 91.44 mm long, 8.38 mm tall and 5.08 mm deep. It uses the solder termination method. This connector has an operating temperature of -55 to 105 °C. TSW-136-23-T-D is housed in black polyester.

Newark:
# SAMTEC  TSW-136-23-T-D  Board-To-Board Connector, 2.54 mm, 72 Contacts, Header, TSW Series, Through Hole, 2 Rows
