BA7725S

模拟压扩的卡拉OK回波系统 Analog compander for KARAOKE echo systems

The and BA7725FS are analog companders designed for KARAOKE echo systems, and logarithmically compress the signal level by 1 / 2 and then logarithmically expand it by a factor of 2. These ICs can be used in combination with the BU9252S or BU9252F to create a digital echo system. These ICs have an internal line mixer amplifier for mixing line input and echo signals. The internal electronic volume control makes it possible to adjust the mixer level and loop level mixer with an external DC voltage.

Features

1 Internal logarithmic 1 / 2 compression circuit and 2 × expansion circuit

2 Internal 2-channel buffer amplifier used as a tertiary low pass filter

3 Internal mixer amplifier that mixes line input and microphone input

4 Internal electronic volume control allows for adjust ment of the echo mixer level and loop mixer level using an external DC voltage.

5 Internal microphone amplifier and microphone input ON / OFF switch
