PAM2306AYPBB

IC REG BUCK SYNC 1.2V 1A 12DFN

* Efficiency up to 96% * Only 40μA typ per channel Quiescent Current * Output Current: Up to 1A per Channel * Internal Synchronous Rectifier * 1.5MHz Switching Frequency * Soft Start * Under-Voltage Lockout * Short Circuit Protection * Thermal Shutdown * Small 12L WDFN3x3 Package * Pb-Free Package and RoHS Compliant

得捷:
IC REG BUCK 1.2V 1A DL 12WDFN

艾睿:
Conv DC-DC Dual Step Down 2.5V to 5.5V 12-Pin WDFN EP T/R

安富利:
The PAM2306 is a dual step-down current-mode, DC-DC converter. At heavy load, the constant frequency PWM control provides excellent stability and transient response. To ensure the longest battery life in portable applications, the PAM2306 provides a power - saving Pulse-Skipping Modulation PSM mode to reduce quiescent current under light load operation.The PAM2306 supports a range of input voltages from 2.5V to 5.5V, allowing the use of a single Li+/Li-polymer cell, multiple Alkaline/NiMH cell, USB, and other standard power sources. The dual output voltages are available for 3.3V, 2.8V, 2.5V, 1.8V, 1.5V, 1.2V or adjustable. All versions employ internal power switch and synchronous rectifier to minimize external part count and realize high efficiency. During shutdown, the input is disconnected from the output and the shutdown current is less than 0.1A. Other key features include under-voltage lockout to prevent deep battery discharge.
