TSW-115-06-T-D

2.54mm 方针

针座 通孔 30 位置 0.100"（2.54mm）

立创商城:
2.54mm 方针

得捷:
CONN HEADER VERT 30POS 2.54MM

艾睿:
Reduce the possibility of accidentally shorting pins when using a printed circuit board with this unshrouded TSW-115-06-T-D header connector from Samtec. This HDR connector&s;s 30 contacts that are made out of phosphor bronze and plated with tin over nickel. This is a 2-row connector. Its pitch is 2.54 mm. It has a header type gender. It has a maximum voltage rating of 550 VAC. It has a straight body orientation. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. This connector has an operating temperature of -55 to 105 °C. It uses the solder termination method. TSW-115-06-T-D is housed in black polyester. This product is 38.1 mm long, 5.21 mm tall and 5.08 mm deep.

Newark:
# SAMTEC  TSW-115-06-T-D  Board-To-Board Connector, 2.54 mm, 30 Contacts, Header, TSW Series, Through Hole, 2 Rows
