SZDF6A6.8FUT1G

ESD 抑制器/TVS 二极管 SC-88 6 EUT DUAL CPR PFH

This quad voltage suppressor is designed for applications requiring transient overvoltage protection capability. It is intended for use in voltage and ESD sensitive equipment such as computers, printers, business machines, communication systems, medical equipment, and other applications. Its quad junction common anode design protects four separate lines using only one package. These devices are ideal for situations where board space is at a premium.

Features

---

 |

.

SC-88 Package Allows Four Separate Unidirectional Configurations

.

Low Leakage < 1 µ A @ 5 Volt

.

Breakdown Voltage: 6.4 - 7.2 Volt @ 5 mA

.

Low Capacitance 40 pF typical

.

ESD Protection Meeting 61000-4-2 Level 4 and 16 kV Human Body Model

Mechanical Characteristics:

.

Void Free, Transfer-Molded, Thermosetting Plastic Case

.

Corrosion Resistant Finish, Easily Solderable

.

Package Designed for Optimal Automated Board Assembly

.

Small Package Size for High Density Applications
