AN5534N

垂直偏转输出IC Vertical deflection output IC

■Overview

The is a vertical deflection output IC for television and CRT monitor. Incorporating a sawtooth wave generator, this IC enables you to form an AC/DC feedback-loop by itself only.

■Features

•Built-in stable sawtooth wave generator independent of input pulse width variation

•Built-in 50 Hz/60 Hz changeover circuit

•Minimum fly-back time of saw-tooth wave signal: 100 µs

■Applications

•Televisions and CRT displays
