I74F786N

Bus Arbiter/Continuous Signal Generator, TTL, PDIP16

DESCRIPTION

The 74F786 is an asynchronous 4–bit arbiter designed for high speed real–time applications. The priority of arbitration is determined on a first–come first–served basis. Separate bus grant BGn outputs are available to indicate which one of the request inputs is served by the arbitration logic.

FEATURES

• Arbitrates between 4 asynchronous inputs

• Separate grant output for each input

• Common output enable

• On board 4 input AND gate

• Metastable–free outputs

• Industrial temperature range available –40°C to +85°C
