JANTX1N968DUR-1

硅500 mW的稳压二极管 Silicon 500 mW Zener Diodes

The popular 1N957DUR-1 through 1N992DUR-1 series of 0.5 watt Zener voltage regulators provides a selection from 6.8 to 200 volts in a standard 5%, 2% and 1% tolerance versions. These glass MELF DO-213AA Zeners feature an internal metallurgical bond and are available in military qualified and commercial RoHS compliant versions.  Military qualified versions are available on the 1N962DUR-1 through 1N992DUR-1 range of part numbers.

艾睿:
Access the reverse breakdown region using a voltage regulator JANTX1N968DUR-1 zener diode from Microsemi. This device has a maximum regulator current of 19 mA. Its maximum power dissipation is 500 mW. Its maximum leakage current is 0.5 μA. Its test current is 6.2 mA. It is made in a single configuration. This zener diode has a minimum operating temperature of -65 °C and a maximum of 175 °C. This zener device has a nominal voltage of 20 V and a voltage tolerance of 1%.

Verical:
Zener Diode Single 20V 1% 25Ohm 500mW 2-Pin DO-213AA Bag
