EAC305

Conn Power F 3POS 14.02mm Solder Lug ST Panel Mount 3 Terminal 1Port

Receptacle, 10 A/15 A Current Rating, 250 VAC Voltage Rating, 1500 V RMS Dielectric Strength

** UL and CSA Approved, International Standard CCE-22

Shell:

.

* Black glass reinforced thermoplastic polyester. UL flammability rating 94 V-O, yellow card #E45575. ** Pins:** Silver-plated brass. ** Terminals:** Electrotinned brass except EAC333, silver-plated brass.

**

EAC333

.

* . 3-pin male receptacle with right angle housing for PC board mount. Rear of panel mounting. PC terminals project 0.125" to extend through PC board. Ground pin is integral with the ground solder lug on rear of receptacle. Two additional 0.136" holes for fastening to panel or chassis. ** EAC309.** 3-pin male receptacle with standard lug terminals. Mounts from front or rear of panel with two #5 screws or 0.125" rivets not supplied. ** EAC311.** 3-pin male receptacle with FASTON terminals. Mounts from front or rear of panel with two #5 screws or 0.125" diameter rivets not supplied. ** .** 3-contact female receptacle front mount with two #4 screws or 0.094" rivets not supplied. ** EAC405.** 3-contact female receptacle with standard solder lug terminals. Snap-in panel mounting. ** EAC409.** 3-pin male receptacle with standard solder lug terminals. Snap-in panel mounting. ** EAC411.** 3-pin male receptacle with FASTON terminals. Snap-in panel mounting.

Front mount. Polycarbonate material.
