PDTA123YE

NPN resistor-equipped transistors; R1 = 2.2kΩ, R2 = 10kΩ

General description

NPN Resistor-Equipped Transistors RET family.

Features

■ Built-in bias resistors

■ Reduces component count

■ Simplifies circuit design

■ Reduces pick and place costs

Applications

■ General-purpose switching and amplification

■ Circuit drivers

■ Inverter and interface circuits
