TLP3212

OPTOISO 5.3kV 2CH TRANS 8DIP

Battery Control

Measuring Instruments

Logic IC Testers / Memory Testers

The TOSHIBA is an ultra-small photorelay suitable for surface-mount assembly. The TLP3212 consists of a GaAs infrared-emitting diode optically coupled to a photo-MOSFET and is housed in a 4-pin package. Its features include low Off-state current and low output pin capacitance.

Features

•  4-pin SSOP SSOP4: 1.8-mm high, 1.27-mm pitch

•  1-Form-A

•  Peak Off-State Voltage: 60 V min

•  Trigger LED Current: 5 mA max

•  On-State Current: 400 mA max

•  On-State Resistance: 1.5Ωmax, 1 Ωtyp.

•  Isolation Voltage: 1500 Vrms min
