CES-112-01-S-D

Conn Socket Strip SKT 24POS 2.54mm Solder ST Thru-Hole Tube

24 Position Receptacle Connector


得捷:
CONN RCPT 24POS 0.1 GOLD PCB


艾睿:
Reduce the possibility of accidentally shorting pins when using a printed circuit board with this socket strip CES-112-01-S-D header connector from Samtec. This SKT connector&s;s 24 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a socket type gender. It has a straight body orientation. It has a maximum voltage rating of 400 VAC. This is a 2-row connector. Its pitch is 2.54 mm. This device has a maximum current rating of 5.5 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This connector has an operating temperature of -55 to 125 °C. CES-112-01-S-D is housed in black polyester. This product is 30.48 mm long, 5.08 mm tall and 5.59 mm deep. It uses the solder termination method.


安富利:
Conn Socket Strip SKT 24 POS 2.54mm Solder ST Thru-Hole Tube


CES-112-01-S-D PDF数据文档
