AS22AP

NKK SWITCHES  AS22AP  /t微型滑动开关

Series AS subminiature slides are designed for use in a low-voltage, low-current, logic-level circuit. When used as intended in a logic-level circuit, the results do not produce hazardous energy. Series AS slide switches have not been tested for UL recognition or CSA certification.

贸泽:
Slide Switches DPDT ON-ON .098" STRAIGHT

e络盟:
滑动开关, DPDT, 0.4VA, 28V, PCB

艾睿:
The AS22AP slide switch from NKK Switches makes turning on or off your circuit a piece of cake. It has a DPDT configuration. This device has a maximum current rating of 0.1 A @ 28VAC 28VDC. This slide switch has a minimum operating temperature of -30 °C and a maximum of 85 °C. The AS22AP slide switch has a PC pin termination style. The maximum AC voltage rating is 28 VAC and the maximum DC voltage rating is 28 VDC. This product is 9.8 mm long, 11.6 mm tall and 9.2 mm deep.

Allied Electronics:
Switch, Slide; DPDT; On None On; 0.098H x 0.094sqr act; PCB Pins

Chip1Stop:
Switch Slide ON None ON DPDT Top Slide 0.1A 28VAC 28VDC 0.4VA 50000Cycles PC Pins Thru-Hole

Verical:
Switch Slide ON None ON DPDT Top Slide 0.1A 28VAC 28VDC 0.4VA 50000Cycles PC Pins Thru-Hole

Newark:
# NKK SWITCHES  AS22AP  Slide Switch, DPDT, On-None-On, Through Hole, 28 V
