ATC17-9-1939PN

AMPHENOL INDUSTRIAL  ATC17-9-1939PN  圆形连接器, AT系列, 插座, 9 触点, 公, 压接, 面板安装

The is a 9-contact Circular Connector, jam nut receptacle. This ATC17-9-1939PN is designed to perform in the demanding applications found on construction and farm equipment, plus truck environments. The ATC17-9-1939PN is a molded thermoplastic receptacle with a positive reverse bayonet retention system and sealed by redundant grommet wire sealing. The 9-pin black receptacle is in accordance with the interface of the J1939 diagnostic connector.

.

Quick mating and unmating, reverse bayonet coupling

.

Environmentally sealed, sealed against moisture and contaminants

.

Contact retention system decreases installation costs and increases reliability

.

1500VAC at 2mA Dielectric withstanding voltage

.

13A at 125°C Current rating

.

60mV 16AWG wire, 13A Contact drop

.

1000MR at 25°C Insulation resistance

.

-55 to +125°C Operating temperature
