97C10SRT

Switch DIP ON OFF SPST 10 Recessed Slide 0.025A 24VDC Gull Wing 1000Cycle 1.27mm SMD T/R

DIP SPST 位置 表面贴装型 滑动式（标准） 触动器 25mA 24VDC

得捷:
SWITCH SLIDE DIP SPST 25MA 24V

立创商城:
97C10SRT

艾睿:
Add push button-type user control to your printed circuit board using the 97C10SRT dual in-line package switch from Grayhill. This device has a maximum current rating of 0.025 A @ 24VDC. It has a SPST configuration. This DIP switch has a minimum operating temperature of -40 °C and a maximum of 85 °C. The 97C10SRT DIP switch has a gull wing termination style. This product&s;s terminal pitch is 1.27 mm. This product is 13.92 mm long, 1.58 mm tall and 6.71 mm deep. The maximum DC voltage rating is 24 VDC.

安富利:
Switch DIP ON OFF SPST 10 Recessed Slide 0.025A 24VDC Gull Wing 1000Cycle 1.27mm SMD T/R

Verical:
Switch DIP ON OFF SPST 10 Recessed Slide 0.025A 24VDC Gull Wing 1000Cycles 1.27mm SMD T/R

Newark:
# GRAYHILL  97C10SRT  Slide Switch,STRAIGHT,SPST,ON-ON,Number Of Positions:10,SURFACE MOUNT Terminal

MASTER:
Switch DIP ON OFF SPST 10 Recessed Slide 0.025A 24VDC Gull Wing 1000Cycles 1.27mm SMD T/R

Electro Sonic:
Switch DIP ON OFF SPST 10 Recessed Slide 0.025A 24VDC Gull Wing 1000Cycles 1.27mm SMD T/R
