2SC1623

2SC1623 NPN三极管 60V 100mA/0.1A 250MHz 200~400 300mV/0.3V SOT-23/SC-59 marking/标记 L6 音频高增益放大器

集电极-基极反向击穿电压VBRCBOCollector-Base VoltageVCBO | 60V \---|--- 集电极-发射极反向击穿电压VBRCEOCollector-Emitter VoltageVCEO | 50V 集电极连续输出电流ICCollector CurrentIC | 100mA/0.1A 截止频率fTTranstion FrequencyfT | 250MHz 直流电流增益hFEDC Current GainhFE | 135~270 管压降VCE（sat）Collector-Emitter Saturation Voltage | 300mV/0.3V 耗散功率PcPower Dissipation | 200mW/0.2W Description & Applications | AUDIO FREQUENCY GENERAL PURPOSE AMPLIFIER NPN SILICON EPITAXIAL TRANSISTOR MINI MOLD FEATURES High DC Current Gain: hFE = 200 TYP. VCE = 6.0 V, IC = 1.0 mA High Voltage: VCEO = 50 V 描述与应用 | NPN硅外延晶体管, 音频通用放大器. 特点: 高DC电流增益,高电压：VCEO= 50 V
