RE225-LF

D-Sub Connector LabcardSRBP solder lacquered Epoxy fibre-glass FR4 1.5mm, hot air levelling HAL-leadfree 2 potential strips Stk nos. 528-0419 & 359-4019 2x9-channel and 2x15-channel Stk nos. 528-0425 & 359-4047 2x25-channel Connector type D-Sub DIN 41652 Single sided Board size 100 x 160 x 1.5mm Copper thickness 35μm hole pitch 2.54mm 0.1 in Hole dia 1.0mm ### DIN 类型矩阵板矩阵板，带有 1 mm 的孔，节距为 2.54 mm。

The is a Prototype PCB Eurocard with 2.54mm pitch spacing. It is made up of FR4 epoxy fibre glass composite and it has dual potential strips.

.

Single-sided 35µm Cu

.

35 x 42 Single-hole conductors Ø2.10mm

.

Connectors D-Sub DIN 41652 2 x 25 channels
