FMC 1,5/3-ST-3,5
PHOENIX CONTACT FMC 1,5/ 3-ST-3,5 插拔式接线端子, 3 路, 160 V, 8 A, 3.5 mm, 24 AWG, 16 AWG
The FMC 1,5/ 3-ST-3,5 is a 3-position green pluggable PCB Terminal Block with tin-plated contacts, a polyamide insulator and the push-in spring connection. This 1952270 terminal block has user-friendly actuation of the terminal point using a screwdriver. Maximum contact and packing density in combination with double-level MCDNV 1,5 base strips. It accepts 24 to 16AWG wire range.
- .
- Ultra-flat design height of just 7.8mm
- .
- Touch connection for voltage testing using a Ø1mm test pin
- .
- 10mm Stripping length
- .
- UL94V-0 Flammability rating
