R5323K022B

R5323K022B LDO电压调整器/稳压电源IC 1.5~4V 带使能脚EN/CE PLP1820-6 marking/标记 C02 短路保护 过热保护

150mA 2ch LDO REGULATOR ;•Low Supply Current Typ. 90µA VR1, VR2 •Standby Mode Typ. 0.1µA VR1, VR2 • Low Dropout Voltage Typ. 0.22V IOUT=150mA , Output Voltage Type • High Ripple Rejection Typ. 75dBVOUT<= 2.4V , Typ. 70dBVOUT<= 2.5Vf=1kHz Typ. 65dBVOUT<= 2.4V , Typ. 60dBVOUT<= 2.5V f=10kHz • Low Temperature-drift Coefficient of Output Voltage Typ. ±100ppm/°C • Excellent Line Regulation Typ.0.02%/V • High Output Voltage Accuracy ±2.0% • Output Voltage Stepwise setting with a step of 0.1V in the range of 1.5V to 4.0V is possible • Built-in chip enable circuit A/B: active high • Built-in fold-back protection circuitTyp. 40mA Current at short mode • Ceramic Capacitor is recommended. 1.0µF or more • Power source for handheld communication equipment. • Power source for electrical appliances such as cameras, VCRs and camcorders. • Power source for battery-powered equipment.
